Huawei Switch S5710-52C-EI with 416 Gbit/s Switching Capacity 192 Mpps Forwarding Performance and 512 MB RAM

Name: Huawei Switch S571052CEI with 416 Gbits Switching Capacity 192 Mpps Forwarding Performance and 512 MB RAM
Brand: Huawei
Price: 3977 USD

Wholesale Huawei Switch S5710-52C-EI with 416 Gbit/s Switching Capacity 192 Mpps Forwarding Performance and 512 MB RAM from china suppliers

Brand Name : Huawei

Model Number : S5710-52C-EI

MOQ : 1

Price : $3977

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 100pcs

Delivery Time : 3-5 days

Description : S5710-52C-EI(48 Ethernet 10/100/1000 ports,4 10 Gig SFP+,with 2 interface slots,without power module)

Condition : Original New; In stock

Contact Now

Huawei Switch S5710-52C-EI (02353169)

Huawei S5710-52C-EI is one of the S5700 Series Switches.S5700 Series Switches provide highly scalable gigabit access for terminals in enterprise campus networks; also ideal for resilient server support and aggregation in large-scale data centers.

Quick Specification

Table 1 show the quick specification.

Model	S5710-52C-EI
Part Number	02353169
Extended Slots	two extended slots that support uplink sub-cards
Subcards supported	2 x 10 GE SFP+ subcard, 8 x 10/100/1,000 BASE-T subcard, and 8 x 1,000 Base-X subcard
Switching Capacity	416 Gbit/s
Forwarding Performance	192 Mpps
Fixed Interfaces	48 x 10/100/1,000 Base-T ports, 4 x 10 GE SFP+ ports
Power Supply	Double hot-swappable AC/DC power supplies
Memory (RAM)	512 MB
Flash	V200R001: 64 MB V200R002 and later versions: 200 MB
Dimensions (W x D x H)	442.0 mm x 420.0 mm x 44.4 mm (17.4 in. x 16.5 in. x 1.75 in.)
Weight	Empty: ≤ 6 kg (13.23 lb) Fully loaded: ≤ 10 kg (22.05 lb)

Figure 1 shows the appearance of S5710-52C-EI.

Huawei Switch S5710-52C-EI with 416 Gbit/s Switching Capacity 192 Mpps Forwarding Performance and 512 MB RAM

Product Details

Figure 2 shows the front panel of S5710-52C-EI.

Huawei Switch S5710-52C-EI with 416 Gbit/s Switching Capacity 192 Mpps Forwarding Performance and 512 MB RAM

Note:

(1)	Forty-eight 10/100/1000BASE-T ports	(4)	One mini USB port
(2)	Four 10GE SFP+ ports	(5)	One console port
(3)	One ETH management port	(6)	One USB port

Figure 3 shows the back panel of S5710-52C-EI.

Huawei Switch S5710-52C-EI with 416 Gbit/s Switching Capacity 192 Mpps Forwarding Performance and 512 MB RAM

Note:

(7)	Ground screw	(10)	ESN label
(8)	Rear card slot 1	(11)	Power module slot 2
(9)	Rear card slot 2	(12)	Power module slot 1

·You can draw ESN label out to view the ESN and MAC address of the switch.

·The switch doesn't provide power supply. The AC or DC power supply must be purchased separately.

Recommended Modules

Table 2 shows the recommended modules.

Model	Description
GE-SFP Optical Transceiver
eSFP-GE-SX-MM850	Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.55km, LC)
SFP-GE-LX-SM1310	Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC)
S-SFP-GE-LH40-SM1310	Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC)
S-SFP-GE-LH40-SM1550	Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 40km, LC)
10G-SFP+ Optical Transceiver
SFP-10G-USR	10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC)
OMXD30000	Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC)
OSX010000	Optical Transceiver, SFP+, 10G, Single-mode 1310nm, 10km, LC)
GE Copper Transceiver
SFP-1000BaseT	Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45)
10GE Interface Card
ES5D21X02S00	2 10 Gig SFP+ interface card (used in S5710EI series)
GE Interface Card
ES5D21G08T00	8 Ethernet 10/100/1000 ports interface card (used in S5710EI series)
ES5D21G08S00	8 Gig SFP interface card (used in S5710EI series)

Compare with Similar Item

Table 3 shows the comparison of S5710-52C-EI, S5700-28C-EI and S5710-28C-PWR-EI-AC.

Model	S5710-52C-EI	S5710-28C-PWR-EI-AC	S5700-28C-EI
Switching Capacity	416 Gbit/s	416 Gbit/s	256 Gbit/s
Forwarding Performance	192 Mpps	156 Mpps	96 Mpps
Fixed Interfaces	48 x 10/100/1,000 Base-T ports, 4 x 10 GE SFP+ ports	24 Ethernet 10/100/1,000 ports, 4 of which are dual-purpose 10/100/1,000 or SFP, 4 x 10 Gig SFP+ ports	24 x 10/100/1,000 Base-T
PoE Available	No	PoE+	No
Extended Slots	two extended slots for uplink subcards.	two extended slots for uplink subcards.	two extended slots, one for an uplink subcard and the other for a stack card.
